| 20′ GP | 40′ GP | |
|---|---|---|
Internal Dimensions (mm & m3) |
||
| Length (Between end paneis): | 6038 mm | 12176 mm |
| Length (Between corner posts): | 5612 mm | 11776 mm |
| Width (Over bottom slide: | 210 mm | 2230 mm |
| Width (Between corner posts: | 2225 mm | 2230 mm |
| Height (Side rail adjacent to post to top casting: | 2213 mm | 1955 mm |
Weight & Payload (kg) |
||
| Tar Weight: | 2750 kg | 4950 kg |
| Maximum Payload: | 31250 kg | 40050 kg |
| Maximum Gross Weight: | 34000 kg | 45000 kg |
External Dimensions (mm) |
||
| Length (Base bottom casting): | 6058 mm | `12192 mm |
| Width (Base bottom casting): | 2438 mm | 2438 mm |
| Height (End Frame Erected): | 2591 mm | 2591 mm |
| Deck Height: | 370 mm | 648 mm |
| Bottom Side Rail Camber Height: | 20 mm | 50 mm |
| Stack Height: | 2591 mm | 2591 m3 |
Strength Tests (kg) |
||
| Concentrated Load (Over center 2 meter span): | 20000 kg | 25400 kg |
| Floor Strength: | 7260 kg | 7260 kg |
| Stacking Test Load per Post | 104000 kg | 104796 kg |
| Lashing Bar Strength: | 5000 kg | 5000 kg |
| Stanchion Pocket Strength: | 500 kg | 500 kg |
| *Container measurements stated above are at estimate to your reference.* |
